overview

The new generation of high -quality rizid solar panels, the spy series, adopts waterproof and anti - corrosion

production technology.
It can withstand harsh weather and has strong corrosion resistance. Through innovative installation methods, with the unique structural design of pre - installed holes and screw fixing, the installation and reliability are greatly enhanced. it can withstand high - pressure water jet cleaning, is noteasy to delaminate, and has strongenvironmental adaptability.

♦ High conversion efficiency
♦ Applicable to all Linkwell modules, with 100% power generation (EL) testing
♦ Ensures no hot spots
♦ First -class PlD resistance
♦ Lightweight installation and low cost

SPV-M/SPV-FL Product Introduction

Model	SPV-M
Peak Power (Pmax)	100W
Maximum Power Point Voltage (Vmp)	18.8V
Maximum Power Point Current (Imp)	5.3A
Open - Circuit Voltage (Voc)	22.5V
Short - Circuit Current (Isc)	5.6A
Module Efficiency	17.3%
Power Tolerance	±3%
Operating Temperature	-40~85°C
Product Certification	CE/CQC/TUV
Dimensions	850x680x2.2mm
Number of Cells	33(3*11)
Weight	2KG
Junction Box	IP65
Output Cable	2.5mmx900mm
Connecter	MC4 compatible
Carton Dimensions	87x70x4cm
Packaging Type	2PCS
Weight	4.3KG
Quantity per Carton (QTY/CTN)	10PCES
Outer Carton Dimensions (meas)	89x72x22cm
Gross Weight (G.W.)	21.5KG

SPV-FL Product Introduction

Model	SPV85-12FL	SPV120-24FL	SPV160-24FL
Rated Output Power (W)	85	120	160
Maximum Power Voltage (V)	20.3	33.8	33.8
Maximum Power Current (A)	4.19	3.56	4.74
Open-Circuit Voltage (V)	24.3	40.5	40.5
Short-Circuit Current (A)	4.59	3.9	5.19
Maximum Module Efficiency (%)	22.5	22.8	22.8
Maximum Voltage Supported by System (V)	1000	1000	1000
Connecter	MC4	MC4	MC4
Number of Cells	18	36	36
Weight	3.5kg	7.2kg	8.5kg
Dimension	975x510x35mm	1002x667x35mm	812x985x35mm
Cell Type	Mono	Mono	Mono
