SPE Series

MODEL                                          SPE1800-21208H SPE3000-22408H SPE3600-22411H SPE5500-24811H

Rated load power

1800W

3000W

3600W

5500W

Parallel operation

Nonsupport

MAX. PV Array Power

2000W

3000W

6000W

6000W

MPPT input interface

lway

Battery rated voltage

12VDC

24VDC

24VDC

48VDC

Lithium battery activation

No (Suitable for lead-acid, Gel and other batteries.)

AC INPUT

Voltage

230VAC

Selectable Voltage Range

170-280VAC (for personal computers)/90-280VAC (for home appliances)

Frequency Range

50Hz/60Hz(Auto detection)

AC OUTPUT

AC Voltage Regulation (Batt. Mode)

230VAC±5%

Surge power

3600W

6000W

7200W

11000W

Transfer Time

10ms(PC)/20ms(Home Appliances)

BATTERY & AC CHARGER

Battery Voltage

12VDC

24VDC

24VDC

48VDC

Floating Charge Voltage

13.5VDC

27VDC

27VDC

54VDC

Overcharge Protection

15.5VDC

31VDC

31VDC

61VDC

Maximum charge current

60A

80A

MAX. PV Array Power

2000W

3000W

6000W

6000W

MPPT Range@ Operating Voltage

55-450VDC

Maximum PV Array Open Circuit Voltage

450VDC

Maximum PV Input Current

10A

20A

Maximum Charging Current

80A

110A

Maximum Efficiency

99%(MPPT Efficiency)

PARAMETER

Communication

RS485

IP level

IP20

Operating Temperature

-10℃to 55℃

Storage Temperature

-15℃to60℃

Dimension. D*W*H(mm)

405*285*100

405*285*100

425*290*100

425*310*120

Net Weight(kgs)

4.5kg

5.5kg

7.0kg

8.0kg
