ESS-50

MICROGRID-PV-STORAGE-DlESEL charging System

产品详情

ESS -50 Product Introduction

Battery model	ES51.2
Capacity	51.2kWh(5.12kWh"10)
Nominal Voltage	512V
Nominal Capacity	100AH
Cabinet Size(mm)	640°830°1900
Weight(kg)	750KG
Charge/ discharge power MAX	100A
Cooling method	Air-cooled
Protection class	IP54
Type of firefighting	Aerosol
Batterie Specifications
Battery Types	51.2V-100AH
Nominal Capacity(KWh)	5.12KWh
Recommen d Charge/ Discharge Current [A]	50
Max. Charge/ Discharge Current{A}	100
Communication	RS485/CAN
Working Temperature	0℃-50℃(Charge) ; - 10℃-50℃(Discharge)
Transport or Storage Temperature Range	-20℃-60℃
Certification	CE/IEC/UL/UN38.3/MSDS
Design Life	10years+
Cycle Life	(0.5C/0.5C-80% DOD)×6000 times
Cooling method	Air-cooled
Certification	UN38.3/MSDS/ROHS
Inverter
Inverter model	SNF20K
Rating	50KW
Overloaded	110%
Rated AC Voltage	400V
Rated frequency	50/60Hz
